Key fob programming

[Infinitech]

Well, I have tried with 4 different scan tools, with Auto Auth and with a Security gateway bypass cable, Jscan and AlfaOBD. I have a new factory key that I purchased at the dealer. They gave me a 4 digit pin at the time I purchased it. Jscan and Alfaobd are both able to extract a 5 digit pin from the truck. I purchased a OBD LinkMX+ for Jscan and AlfaOBD use. Jscan is on my Ipad. AlfaOBD is on my windows laptop. I no longer have an Android phone or tablet anymore so I can't try that combo.
So long story short, I have been unsuccessful at adding a Key to my truck. (bought it a couple months ago with one key). Tomorrow, I'm getting it programmed by a key vendor. On both Alfa and Jscan, they will get me to the step that says to touch the key to the start button and they both have the error: Fobik is not Blank.
My truck is a 2022 Ram Limited with 6 button key fob. Lock, Unlock, Remote start, Panic, Tailgate and Air suspension buttons. Even though I haven't succeeded at programming, I am open to suggestions and would like to hear how anyone else succeeded.



[skyhawk42]

Ma

Well, I have tried with 4 different scan tools, with Auto Auth and with a Security gateway bypass cable, Jscan and AlfaOBD. I have a new factory key that I purchased at the dealer. They gave me a 4 digit pin at the time I purchased it. Jscan and Alfaobd are both able to extract a 5 digit pin from the truck. I purchased a OBD LinkMX+ for Jscan and AlfaOBD use. Jscan is on my Ipad. AlfaOBD is on my windows laptop. I no longer have an Android phone or tablet anymore so I can't try that combo.
So long story short, I have been unsuccessful at adding a Key to my truck. (bought it a couple months ago with one key). Tomorrow, I'm getting it programmed by a key vendor. On both Alfa and Jscan, they will get me to the step that says to touch the key to the start button and they both have the error: Fobik is not Blank.
My truck is a 2022 Ram Limited with 6 button key fob. Lock, Unlock, Remote start, Panic, Tailgate and Air suspension buttons. Even though I haven't succeeded at programming, I am open to suggestions and would like to hear how anyone else succeeded.

ke sure the working fob is not near the truck when trying to program the new fob, otherwise it may read the old fob and tell you it’s not blank



[Infinitech]

Ma

ke sure the working fob is not near the truck when trying to program the new fob, otherwise it may read the old fob and tell you it’s not blank

I did try that. Had the key FOB far away from the vehicle. Also, my key vendor was unable to program it. I have an appt at the dealer tomorrow.



[Infinitech]

Update. Picked it up from the dealer. They said the new key was bad and they replaced it and programmed it. So maybe I could have programmed it. Maybe I’ll order a cheap one and try it out. I have 2 working keys and don’t want to risk trying to erase them and start over.



[StuartV]

Update. Picked it up from the dealer. They said the new key was bad and they replaced it and programmed it. So maybe I could have programmed it. Maybe I’ll order a cheap one and try it out. I have 2 working keys and don’t want to risk trying to erase them and start over.

I got a 3rd key off eBay for something like $40 and had it programmed by a local locksmith.

I like having 3 keys. Use 2 as normal and always have the peace of mind of that 3rd key stored safely at home, for just in case.



[Driver]

For fob programing I tried the vlinker and Jimmy07s instructions and suggested tools/components and it worked like a charm.

It is the holy grail for gen 5 ram fob programing. Cost about $110 for first fob incl jscan. Cost for additional fobs is about $60 incl jscan!!! You do have to install the jscan app, and they charge $30 per vin.

I found the hardest part of the job was locating and removing 2 multi pin cables above your left knee under the dash. The trick there is they are to the left of a metal bracket above your left knee, and the clips to remove them are on the left side of the clip, or left side of truck.

You pull the cables down vertically after unclipping them. I also found it's easiest to remove the knee panel in front of the fuse box. You can't see the cables from the removed knee panel, but you can reach in and pull down on one cable at a time with your right hand, while releasing the clip on the left side with your left hand.

Here's Jimmy07s video showing how to locate the cables.

You best use the EXACT components he has tested or you might have trouble !

Somewhere perhaps in this thread Jimmy07 listed links where you can buy the vlinker, the fob, and the security cable. (mostly amazon) If you can’t find them here, you can find them on another Ram forum in post #4 Need a new remote



[Puckstopper55]

How can you get the 5 digit code with AlfaOBD?



[theblet]

How can you get the 5 digit code with AlfaOBD?

I don't think Alpha can pull it. But jscan can



[jbergy74]

Thanks Jimmy07, I just programmed the ebay fob successfully with Jscan and a vlinker.
