Great job my friend. As an EE, and a guy whose been installing electronics in cars forever, I recommend the following:Added some grill lights to the Rebel this weekend.
1. LEDs use very little power...typically milliamps. Therefore, a 10A fuse is WAAAY to big. I recommend a 1A fuse, if you can find one, or a 2-3A, but no more
2. Do not use BUTT connectors that can be subjected to weather (even though you heat shrink wrapped them) try the solder connectors in my link below and then place an additional piece of heat shrink tubing for additional protection
Otherwise...I thought you did a nice job explaining the circuit, using a relay (great idea) and achieving a nice look. Personally, I'd go for the 3-LED look and not the 4, but that's just me One above the R, another centered above the A and the last centered above the M.
