Realistic lift <=2" options (Bilstein vs Mopar)

RedWhite&PatriotBlue

Active Member
Joined
Jan 22, 2021
Messages
88
Reaction score
40
Maybe someone can shed some light on this, as I've read over 40 pages of different threads and I think I more confused now, than when I started. My truck is a non-ORP Laramie crew cab. I am on the fence between lifting the truck with the 2" Mopar lift, or going with Bilstein 5100s to get <2" and nearly level (I want some rake as I tow and haul). I will be putting larger off road tires, but no bigger than 295/60/20s. I'm not married to that tire, but will at least go 275/60/20s, just don't want rubbing and need better offroad tread.

I am a function over form kind of guy, and the truck does and will see some rutted gravel roads, fire roads, and creek crossings in its life. I would like suspension travel and not just looks. With that being said, I don't need more than 2" of lift to accomplish this, and realistically I think 1"-2" and bigger tires would do the trick. What's the best way to accomplish this goal?

The Mopar lift comes complete, but if I go the Bilstein route, will I need front UCAs? What about track bar re-location? Do I need ORP springs? Anything else I am forgetting?


Doc33

Active Member
Joined
Sep 7, 2019
Messages
160
Reaction score
70
Also depends on your budget, Bilstein level would be cheaper.


Doc33

Active Member
Joined
Sep 7, 2019
Messages
160
Reaction score
70
Next question is do you want to lift front and back which the mopar kit does or just level the front with the bilstein?


5thGenLoco

Active Member
Joined
Apr 23, 2020
Messages
181
Reaction score
155
Bils at 2" in front, 1" rear spacer, you'll have some rake for towing. No need for new uca's or track bar relocation bracket. The Bils ride nearly as smooth as factory but handle bumps and such better.


‘19ramlveryeha

Well-Known Member
Joined
Jun 9, 2019
Messages
343
Reaction score
224
Bils at 2" in front, 1" rear spacer, you'll have some rake for towing. No need for new uca's or track bar relocation bracket. The Bils ride nearly as smooth as factory but handle bumps and such better.

This is correct. Since non orp you won’t need the ucas. Bilsteins are fantastic. Ride has been great so far. I went with the 285/60r20. A “33.5’” tire. Really once it’s mounted it come out to like 32.75”. But fits the wheel well nicely. Could go to 34” without a problem. You might be able to do 35”.



Sent from my iPhone using Tapatalk


RedWhite&PatriotBlue

Active Member
Joined
Jan 22, 2021
Messages
88
Reaction score
40
So a guy could go with just the bilstein 5100s in front and a 1" in spacer in back and that would essentially by the parts needed? I'd likely go ahead and do bilsteins in the back if I take out the shock to add the spacer. With Bilstein's how does the ride compare to stock? I saw 5thGenLoco said "nearly" as good, is there anything that is worth other than maybe a little harsher with bigger tires?

Really appreciate you guys! I love the knowledge in this forum.


BostonBLS

Active Member
Joined
Sep 12, 2019
Messages
185
Reaction score
103
I have a non-orp laramie. I picked up a set of rebel front bilstein take offs. This will net you a 1" lift in the front. They also came with a 1/2" spacer for a total of 1.5" over stock. But you could leave them out and just get the 1". Also came with the rear bilstein shocks. All of this I paid less than bilsteins, don't have to switch the springs, and it is technically OEM.

Just another option if you can find a set of rebel (or ORP even for non bilstein but still 1" lift) take offs.


5thGenLoco

Active Member
Joined
Apr 23, 2020
Messages
181
Reaction score
155
So a guy could go with just the bilstein 5100s in front and a 1" in spacer in back and that would essentially by the parts needed? I'd likely go ahead and do bilsteins in the back if I take out the shock to add the spacer. With Bilstein's how does the ride compare to stock? I saw 5thGenLoco said "nearly" as good, is there anything that is worth other than maybe a little harsher with bigger tires?

Really appreciate you guys! I love the knowledge in this forum.
Yes, that is all you'd need although not sure if the stock rears are long enough for the added 1". The Bils are, however. IMO, the stock ride was too soft and had poor rebound control. Much better now with the Bils but, it won't be as soft/sloppy if that is what you're wanting.


RedWhite&PatriotBlue

Active Member
Joined
Jan 22, 2021
Messages
88
Reaction score
40
Yes, that is all you'd need although not sure if the stock rears are long enough for the added 1". The Bils are, however. IMO, the stock ride was too soft and had poor rebound control. Much better now with the Bils but, it won't be as soft/sloppy if that is what you're wanting.
I think I'm leaning towards this option now. I could get a set Bilsteins and be good to go for what I want vs the entire mopar kit.


DenCoRam

Active Member
Joined
Dec 9, 2020
Messages
65
Reaction score
122
Like you, I read a lot of threads and had a tough time choosing. I wanted to lift the front, but <2" while improving performance. I settled on the Bilstein 6112 fronts and 5160 rears.


RedWhite&PatriotBlue

Active Member
Joined
Jan 22, 2021
Messages
88
Reaction score
40
Like you, I read a lot of threads and had a tough time choosing. I wanted to lift the front, but <2" while improving performance. I settled on the Bilstein 6112 fronts and 5160 rears.
How is the ride with your setup? I was looking at the 5100s but do the remote reservoir 5160s make a noticeable difference?


DenCoRam

Active Member
Joined
Dec 9, 2020
Messages
65
Reaction score
122
How is the ride with your setup? I was looking at the 5100s but do the remote reservoir 5160s make a noticeable difference?
Not really any noticeable difference in ride from stock rebel suspension. Haven't gotten a chance to put it through it's paces in any rough stuff.


RedWhite&PatriotBlue

Active Member
Joined
Jan 22, 2021
Messages
88
Reaction score
40
After some researching on here and elsewhere, I think I'm going to go with the following (if Bilstein's come back in stock):
- Bilstein 6112 setup
- Icon 1.5" Rear Coil Springs
- Mopar 2" UCA
- Tires 295/60/20
Any concern anyone sees? I'd like to go with the Rough Country UCAs, but they explicitly state 3-3.5" suspension lift installs only. With this setup, I can run 1.5" lift in the rear, and 2.2" lift in front on Bilstein setting #7, and keep roughly 1.3" rake.

Any other UCS recommendations for this setup?


z0n3

Ram Guru
Joined
Jun 16, 2019
Messages
1,722
Reaction score
1,371
After some researching on here and elsewhere, I think I'm going to go with the following (if Bilstein's come back in stock):
- Bilstein 6112 setup
- Icon 1.5" Rear Coil Springs
- Mopar 2" UCA
- Tires 295/60/20
Any concern anyone sees? I'd like to go with the Rough Country UCAs, but they explicitly state 3-3.5" suspension lift installs only. With this setup, I can run 1.5" lift in the rear, and 2.2" lift in front on Bilstein setting #7, and keep roughly 1.3" rake.

Any other UCS recommendations for this setup?
You can also go with ready lift UCA's. The 2" level kit on amazon is like $375 and you can sell the spacers. Those UCA's will certainly handle 2.2" of lift.
