Installing Factory Trailer Brake Controller and DIY Software Update

[khzinger]

What site did you purchase all the parts from for $128?

It came from a place called southfork jeep ram from texas



[OBX_Rebel]

New member here with a 2019 Rebel. Thanks to this post, I will be saving money I can put into a set of Timbrens or air bags. I haven't ordered the stuff to flash the system yet. Other than the FCA bypass piece, can someone post links to the items I would need to flash the system from an iPhone or Windows PC? I want to make sure I get the correct items. Thanks



[OBX_Rebel]

Never mind....I think I found what I was looking for.

On Amazon:
Security Bypass: sportuli Fit for Chrysler -12+8 Cable Adaptor for Autel MaxiSys MS908 MS906S 908S MS905

IOS Compatible OBD2: vgate iCar Pro Bluetooth 4.0 (BLE) OBD2 Fault Code Reader OBDII Code Scanner Car Check Engine Light iOS iPhone iPad/Android

In App Store:
OBD JScan



[khzinger]

I did my install today, amazingly easy. I used my kindle fire as my Android device. The hardest part was searching for the trailer tow module in the AlphaOBD II menu. I would up buying and using this OBDII dongle, worked great decent quality. 12.99 with an additional $2 off on amazon. I have a Jeep Cherokee as well so the secuirty bypass is good for both vehicles. The best past is that I didn't have to waste time at the dealership. I wish I would have negotiated for them to throw it in for free when I bought my truck. I will never have an under-dash unit again. If I can avoid it. Going to take the Travel Trailer out tomorrow for the weekend. I can't wait to try it.

parts- $128
Dongle- 12.99
Security bypass 49.99
download- 49.99
Total 239.97

Amazon.com: Veepeak Mini Bluetooth OBD2 Scanner for Android, Car OBD II Diagnostic Scan Tool Check Engine Light Code Reader, Supports Torque Pro, OBD Fusion, DashCommand, Car Scanner App: Automotive

Buy Veepeak Mini Bluetooth OBD2 Scanner for Android, Car OBD II Diagnostic Scan Tool Check Engine Light Code Reader, Supports Torque Pro, OBD Fusion, DashCommand, Car Scanner App: Code Readers & Scan Tools - Amazon.com ✓ FREE DELIVERY possible on eligible purchases

www.amazon.com



[20nightEdition]

I did my install today, amazingly easy. I used my kindle fire as my Android device. The hardest part was searching for the trailer tow module in the AlphaOBD II menu. I would up buying and using this OBDII dongle, worked great decent quality. 12.99 with an additional $2 off on amazon. I have a Jeep Cherokee as well so the secuirty bypass is good for both vehicles. The best past is that I didn't have to waste time at the dealership. I wish I would have negotiated for them to throw it in for free when I bought my truck. I will never have an under-dash unit again. If I can avoid it. Going to take the Travel Trailer out tomorrow for the weekend. I can't wait to try it.

parts- $128
Dongle- 12.99
Security bypass 49.99
download- 49.99
Total 239.97

Amazon.com: Veepeak Mini Bluetooth OBD2 Scanner for Android, Car OBD II Diagnostic Scan Tool Check Engine Light Code Reader, Supports Torque Pro, OBD Fusion, DashCommand, Car Scanner App: Automotive

Buy Veepeak Mini Bluetooth OBD2 Scanner for Android, Car OBD II Diagnostic Scan Tool Check Engine Light Code Reader, Supports Torque Pro, OBD Fusion, DashCommand, Car Scanner App: Code Readers & Scan Tools - Amazon.com ✓ FREE DELIVERY possible on eligible purchases

www.amazon.com

View attachment 64632

How did you use the kindle ? Thanks


Sent from my iPhone using Tapatalk



[LoNeStAr]

For anyone in Houston, especially the north side that is adding the trailer brake controller and needs to get the flash, go see Dan Mittag at DeMontrond. $100 for the flash plus they have a 10% off coupon on their website. Worth it for $90



[MeyerzRam]

Thanks for the write up. Ordered everything today. Can't believe it's half the price to buy the parts from MOPAR vs. the kit with the parts.



[LoNeStAr]

The kit with parts on EBay is only $156



[khzinger]

How did you use the kindle ? Thanks


Sent from my iPhone using Tapatalk

I went to the app store on the Kindle, purchased the AlphaOBD app, used the USB Bluetooth dongle that I posted previously. It worked great.



[khzinger]

Never mind....I think I found what I was looking for.

On Amazon:
Security Bypass: sportuli Fit for Chrysler -12+8 Cable Adaptor for Autel MaxiSys MS908 MS906S 908S MS905

IOS Compatible OBD2: vgate iCar Pro Bluetooth 4.0 (BLE) OBD2 Fault Code Reader OBDII Code Scanner Car Check Engine Light iOS iPhone iPad/Android

In App Store:
OBD JScan

this is the security bypass I used. https://www.obdgenie.com/products/2...MIquPT9LGW6wIV54FaBR3vLwNPEAYYBSABEgJmSfD_BwE



[Vinslayer]

Great to hear. My TBC will be here next week. If JScan has IOS I am going to look into it. Thanks for the heads up

Were you able to get this to work with JSCan on the DT models? Just installed the BC on my 2020 1500. Just need to program now and weighting between all the options. Dealership wanted $150 for 1 hour of labor for programming. Even though I’m sure it takes like two minutes.



[LoNeStAr]

I didn’t end up buying the JSCAN. I found a dealer that would do it for $100. They also had a 10% off coupon on their site so got it done for $90



[Rau]

I didn’t end up buying the JSCAN. I found a dealer that would do it for $100. They also had a 10% off coupon on their site so got it done for $90

Where is this dealer located? I need to install one.


Sent from my iPhone using Tapatalk



[LoNeStAr]

Conroe, TX



[Rau]

Conroe, TX

Great, I am in the woodlands.

So I just need to buy replacement part and contact Dan?


Sent from my iPhone using Tapatalk



[LoNeStAr]

Have you already installed the controller and module? The $90 is just to program the computer. You will need to install the controller and module.



[Rau]

Have you already installed the controller and module? The $90 is just to program the computer. You will need to install the controller and module.

No, I didn’t install anything yet. Can you please share where I can get them from?
Also does it work like original part when it is installed and flashed?


Sent from my iPhone using Tapatalk



[LoNeStAr]

19 RAM 1500 DT Body Integrated Trailer Brake Controller Mopar 82215278AE for sale online | eBay

Find many great new & used options and get the best deals for 19 RAM 1500 DT Body Integrated Trailer Brake Controller Mopar 82215278AE at the best online prices at eBay! Free shipping for many products!

www.ebay.com

its an OEM kit



[MeyerzRam]

Thanks for the great write up. This is where I got stuck......the menu looks different on the new release for Windows 10. I was connected, but no little car. I sent an email to ALFAOBD to see what the issue is. If the Windows 10 steps are slightly different, I will post them up.

Once connected click on the little car with the hood up and navigate all the way to the bottom of this menu
Select "Car Configuration Change"
In the next menu you will need to make the following changes one at a time. Be sure to validate that the change was made by selecting each option and seeing what it is set at according to AlfaOBD after you set the option. The options you need to change and the values for them are as follows:
ITBM/HWM Integrated Trailer Brake Module: Change to "ENABLED"
Trailer selected CSM: Change to "Yes"
Trailer name CSM: Change to "Yes"
Trailer type CSM: Change to "Yes"



[spaniel43]

Guys I just finished installing my TBC and used an app different from AlphaOBD called OBD JScan. I used it before on Jeeps which is what it was developed for but they also support many other FCA vehicles including Ram Trucks. I'm not knocking AlphaOBD but this app is very simple with an easy to use interface. I run it on Android but I believe it's available on IOS as well. I also used the same bluetooth adapter (MX OBD) and SGA. Thanks to all of the previous posters as this thread made the install very easy. Message me with any questions about JScan. Also, our 5th Gen trucks will not show up but I used the 2018 DS model and was able to activate the TBC as well as change tire sizes and remove fog light drop-off with high beams all in about 3 minutes.

Do you know if it'll work with 5gen Ram trucks?

Sent from my SM-G973U using Tapatalk
