That's not the same. It's for a 2500. They have a different dash and wiring harness. Even the part number in your first post is for the HD trucks.
For the Upfitter switch bank, it doesn't matter if it's a HD part as long as the top row buttons are correct. All the info is in the thread I linked.
68476024AB or 68376640AE is the TH, Traction, Park, Park, switch panel (gloss)
ALL the part numbers for ALL the switch combos in glossy and matte finish are in one of
@Jimmy07 's posts on HDRAMS.COM
There are quite a few threads about Adding Aux switches and AlfaOBD to our trucks out there. I did hours of reading them and watching numerous videos on it as well as messages back and forth to get this installed on my truck. I wanted to make a DIY for someone else that wants to do it and keep...
hdrams.com
An Aux PDC and wiring has to be added regardless and unless one was lucky enough to get ahold of the factory upfitter kit, that's going to be aftermarket or built using OEM parts in the very last thread I linked below.
Has anyone looked into this kit for aux switches yet? Site says its compatible with all trims and all engines for '21. Also what about the TRX Aux panel, is that what this part is supposed to be? https://www.mymoparparts.com/oem-parts/mopar-ram1500-auxiliary-switch-kit-82216449aa
5thgenrams.com
OP here is another thread with the same question in regards to adding OE aux switches. i have not personally seen it done on this forum.
it seems to be a hard install due to the BCM and pin outs. i would say go after market like a trigger or switch pros or dare i say AUXBEAM lol im using a blazer controller and has been going strong for 2 years now no complaints at ALL! (running 32" single row led bar, A pillar pods and a light under the hood.)
It's been done. 2021+ DT BCM will support it. Again, the info is in the thread I linked earlier. Start reading about half way through.
Aftermarket is always an option, some folks just prefer a factory look and are willing to put in the effort.
There's a great writeup on HDRAMS that details everything needed. I'm to understand this only works on 2021+ DT and (all) 19+ HD trucks.
There are quite a few threads about Adding Aux switches and AlfaOBD to our trucks out there. I did hours of reading them and watching numerous videos on it as well as messages back and forth to get this installed on my truck. I wanted to make a DIY for someone else that wants to do it and keep...
hdrams.com
